With the complete system weighing 4.7kg, not only does the 2-way Bonnet Pod offer valuable weight-saving gains, but the lighting performance of the Triple-R 1000 Elite’s is unrivalled considering the lamps’ size and low power consumption. Moreover, the products are designed, engineered, and manufactured in the UK to the most exacting standards, and benefit from input received from the very highest levels of professional rally motorsport.
The lamps profit from E-mark certification, enabled by dual-output functionality which allows the lights to also run at a reduced output just within the limit of the road-legal regulations (ensuring compliance with some FIA regulated rally series). When operating at their full ‘E-Boost’ output levels the lights combine to produce 20,272 lumen. Through a combination of highly efficient high-intensity LEDs, advanced electronics design, and vacuum metallised long-range optics, the 1 lux line reaches to just over 960m, and with an excellent spread of light in the mid to long-range. With the colour temperature of the LEDs carefully selected at 5000k to improve sharpness and definition of the road and objects ahead, nothing has been left to chance with regards performance or build quality.
The bonnet pod, made from carbon-fibre with glass laminate layers (to ensure compliance with some FIA regulated series), comes with the lights pre-mounted. A fine-adjustment mechanism allows for quick and easy vertical adjustment of the lights +/-5deg, alongside <2deg outboard adjustment permits more left/right spread of light.
The 2-Way Rally Lamp Bonnet Pod is recommended for use with Linear-6 Elite corner lights, mounted in a horizontal orientation. A bespoke pod exists for Fiesta R5 customers, for all other customers it is recommended to mount the corner lights with our Aluminium Side Bracket Kit. Where the requirement is for corner lights mounted in a vertical orientation, we would recommend our ST4 Evolution high performance spotlights.
